Especificaciones

Aplicación
Client PCs, Game Consoles
Interfaz
PCIe Gen 4.0 x4, NVMe 2.0
Dimensiones
80 x 22 x 2.3 mm
Peso
Max 9.0g Weight
Rendimiento
Up to 7,450 MB/s * Performance may vary based on system hardware &
configuration
Escritura secuencial
Up to 6,900 MB/s * Performance may vary based on system hardware &
configuration

Detalle de especificaciones
Características generales

Aplicación
Client PCs, Game Consoles
Capacidad
1,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or otherwise)
Formato
M.2 (2280)
Interfaz
PCIe Gen 4.0 x4, NVMe 2.0
Dimensiones
80 x 22 x 2.3 mm
Peso
Max 9.0g Weight
Memoria de almacenamiento
Samsung V-NAND 3-bit MLC
Controller
Samsung in-house Controller
Memoria caché
Samsung 1GB Low Power DDR4 SDRAM

Características especiales

Soporte TRIM
Supported
Soporte S.M.A.R.T
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encriptación
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN
Not supported
Soporte Modo Suspensión en dispositivo
Sí

Rendimiento

Lectura secuencial
Up to 7,450 MB/s * Performance may vary based on system hardware &
configuration
Escritura secuencial
Up to 6,900 MB/s * Performance may vary based on system hardware &
configuration
Lectura aleatoria (4KB, QD32)
Up to 1,200,000 IOPS * Performance may vary based on system hardware &
configuration
Escritura aleatoria (4KB, QD32)
Up to 1,550,000 IOPS * Performance may vary based on system hardware &
configuration
Lectura aleatoria (4KB, QD1)
Up to 22,000 IOPS * Performance may vary based on system hardware &
configuration
Escritura aleatoria (4KB, QD1)
Up to 80,000 IOPS * Performance may vary based on system hardware &
configuration

Entorno

Consumo energético medio
*Average: 5.4 W*Maximum: 7.8 W (Burst mode)* Actual power consumption may
vary depending on system hardware & configuration
Consumo energético (Idle)
Max. 50 mW * Actual power consumption may vary depending on system
hardware & configuration
Voltaje soportado
3.3 V 5 % Allowable voltage
Durabilidad (MTBF)
1.5 Million Hours Reliability (MTBF)
Temperatura
0 - 70 Operating Temperature
Golpes
1,500 G & 0.5 ms (Half sine)

Accesorios

Kit de instalación
Not Available

Software

SW de gestión
Magician Software for SSD management
