SPECIFICATION

CAMERA Image Sensor:

1/2.8” Progressive Scan CMOSMax. Resolution: 5MP (2592×1944)Electronic Shutter: Auto/Manual, 1/5 ~ 1/20,000sMin. Illumination:Color: 0.03 Lux @ (F1.6, AGC ON)B/W: 0 Lux @ (IR LED ON)Day & Night: IR cut filterIllumination Distance: Up to 40 m (131.2 ft)Illumination On/Off Control: Auto/ManualPan/Tilt/Rotation Range:Pan: 0˚ ~ 355˚Tilt: 0˚ ~ 80˚Rotation: 0˚ ~ 360˚

LENS

Lens Type: MotorizedIris: Fixed IrisFocal Length: 2.7 ~ 13.5 mmF Number: F1.6Angle of View:H: 87.5° ~ 26°V: 64.8° ~ 19.9°

VIDEO Streaming Capability:

3 StreamsStream/Frame Rate:Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720 @ 25/30fpsStream2: D1, VGA, CIF @ 25/30fpsStream3: VGA, CIF, QVGA @ 25/30fpsBit Rate Control: CBR/VBRBit Rate:Stream1: 200kbps ~ 12MbpsStream2: 100kbps ~ 6MbpsStream3: 100kbps ~ 3MbpsRegion of Interest: Off/On (8 Zones, Rectangle)Smart Encode: Support

IMAGE Image Adjustment:

Brightness, Sharpness, Contrast, Saturation adjustableAisle Mode: SupportMirror: SupportWhite Balance: Auto/ManualDay/Night Setting: Auto, Day, Night, TimeSmart IR: SupportNoise Reduction: 2D/3D DNRImage Enhancement: HLC, BLC, DefogWide Dynamic Range: True WDRS/N Ratio: 55dBMotion Detection: SupportPrivacy Masking: Support

SMART FUNCTION

Multi-Object Detection: Supports face, human, vehicle detection and captureSmart Events: Intrusion, Single line crossing, Double line crossing, Loitering, Wrong way, People counting, Support alarm triggering by specified target types (human and vehicle)

AUDIO Compression: G.711, RAW_PCMBit Rate: 8kbps, 16kbps, 64kbps

NETWORK Protocols:

IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSLInteroperability: ONVIF, SDK, CGIStreaming Method: UnicastMax. User Access: 10 UsersWeb Viewer: IE11, Chrome, Firefox, Microsoft Edge - Languages: English, Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian (Default: English)

INTERFACE Network Interface:

1 Ethernet (10/100 Base-T) RJ-45 ConnectorAudio Interface: 1ch Input, 1ch OutputBuilt-in Microphone: YesAlarm Interface: 1ch Input, 1ch OutputReset Button: SupportSD Card Slot: Built-in, up to 256GB

ELECTRICAL Power Supply: DC12V (-25% ~ +10%) / POE (IEEE 802.3af)Power Consumption: Max 7.5 W

Operating Temperature-40°C ~ 55°C (-40°F ~ 131°F)

Operating HumidityLess than 90% RH

Ingress ProtectionIP66

CertificationsCE/FCC

CasingMetal + PlasticDimensions: 140×119.2 mm (5.51×4.69 inch)Net Weight: 0.9 kg (1.98 lb)
